Floor Plans
Measured internal layouts showing walls, openings, fixtures and key building features.
Manchester-based survey team · UK-wide coverage
Measured Building Surveys Across the UK
Accurate floor plans, elevations, sections, point clouds and Revit models for refurbishment, planning, design and construction projects.
Quote response within 24 hours
CAD, PDF, Revit and point cloud outputs
Support after delivery
Survey data prepared for real project use
From site capture to checked drawings and coordinated models.
20+Years’ experience
UKWide project coverage
3DLaser scanning capability
2D & 3DFlexible deliverables
Existing-building information
Accurate Building Information for Better Project Decisions
Measured building surveys give your team a reliable record of the property as it exists today. We capture the required building information on site and produce clear drawings, models and point clouds that can be used for planning, design, coordination and construction.
Every scope is reviewed before attendance so the survey matches the level of detail and outputs your project actually needs.
Survey outputs
What Your Measured Building Survey Can Include
Select only what your project requires, from straightforward 2D drawings to a coordinated Revit model.
Roof Plans
Roof geometry, ridges, valleys, openings and visible rooftop elements.
External Elevations
Building façades, openings, levels, architectural details and visible defects.
Internal Elevations
Detailed room elevations for fit-out, conservation and design work.
Building Sections
Vertical relationships, floor levels, ceiling heights and structural form.
Site Plans
Building footprint and surrounding site information where required.
Revit Models
Coordinated 3D models developed from measured survey and point cloud data.
Registered Point Clouds
Accurate scan data for remote review, coordination and future modelling.
Project applications
When You May Need a Measured Building Survey
A measured survey is useful whenever design decisions depend on the current size, shape, levels or condition of an existing building.
Extensions and refurbishments
Planning applications
Property conversions
Interior fit-outs
Structural alterations
Listed and historic buildings
Record drawings
Scan-to-BIM projects
Who we support
Survey Data for the Whole Project Team
ArchitectsDevelopersEngineersContractors
Interior DesignersBIM TeamsBuilding OwnersProperty Consultants
Simple process
How It Works
Share your project details
Send the property location, required outputs and any available drawings.
Receive your quotation
We review the scope and normally respond within 24 hours.
We complete the survey
Our team captures the agreed building information on site.
Receive checked deliverables
Your drawings, model or point cloud are quality checked before issue.
Practical reassurance
Why Project Teams Choose Us
Clear scope before attendanceWe confirm what is included before the survey begins.
Experienced survey teamBuilding information is captured with the intended deliverables in mind.
Advanced survey equipmentLaser scanning, GNSS and total station methods are used where appropriate.
Files prepared for design useOutputs are structured to support the next stage of your project.
Flexible formatsChoose CAD, PDF, Revit, IFC or point cloud outputs.
Post-delivery supportOur team remains available for questions and agreed revisions.
Project proof
Recent Measured Survey Projects
Examples of measured building, topographical and Revit survey work completed by Survey2Plan.
Residential · Liverpool
Detailed Measured Building Survey
A geo-coordinated Revit model and 2D elevation outputs developed from point cloud data, retaining existing irregularities and visible building details.
View project →
Commercial · Birmingham
Measured Building and Topographical Survey
A coordinated Revit model covering visible architectural, structural and MEP information to support ongoing construction and coordination.
View project →
Grade I Listed · Oxfordshire
Historic Building and Topographical Survey
Detailed external and internal survey information capturing ornamental features, vaulted ceilings, mouldings and historic door details.
View project →
Additional proof · Boston
View project →
Phased 2D and Geo-Coordinated Revit Delivery
Floor plans were issued first, followed by a detailed Revit model covering architectural, structural and key MEP information.
Flexible delivery
Receive the Files Your Team Needs
Local coverage
Measured Building Survey Coverage
Alongside UK-wide coverage, explore local measured building survey information, service details and project examples for Manchester, Liverpool and Lancashire.
Manchester
Measured building surveys across Manchester and Greater Manchester, supported by genuine local project examples.
Liverpool
Measured building surveys across Liverpool and Merseyside, including detailed residential Revit survey projects.
Lancashire
Measured building surveys across Lancashire, including Preston, Blackburn, Burnley, Lancaster, Chorley and surrounding areas.
Common questions
Measured Building Survey FAQs
How much does a measured building survey cost?
Cost depends on the building size, complexity, location, access and required deliverables. Share the project details and we will provide a scope-based quotation.
How quickly can the survey be completed?
Timescales vary by project. We confirm the expected site and delivery programme within the quotation.
Which file formats can you provide?
Common outputs include DWG, PDF, RVT, IFC and registered point cloud formats such as RCP, RCS and E57.
Can you provide a Revit model?
Yes. Revit models can be developed from survey and point cloud data to an agreed scope and level of detail.
Can you survey occupied buildings?
Yes. We can plan the survey around access restrictions and occupied areas, subject to the property and project requirements.
Do you cover projects across the UK?
Yes. We are Manchester-based and support measured building survey projects throughout the UK.
What do you need to provide a quote?
Please send the property address or postcode, approximate size, required drawings or model outputs, preferred programme and any existing plans.
Request a quotation
Tell Us About Your Project
Share your project location, required deliverables and any available drawings. Our team will review the scope and normally respond within 24 hours.
Need Accurate Existing-Building Information?
Speak to our survey team about your project scope, programme and required outputs.
